6 Series Low Profile Digitizer

Applications requiring high-speed digitizers shouldn’t trade-off performance when turning on channels. The 6 Series Low Profile Digitizer sets a new standard by not interleaving sample rate, bandwidth or record length. You get the fastest and most accurate performance from your digitizer – all in a 2U space.

  • 25 GS/s on all 4 channels
  • DC to 8 GHz on all 4 channels
  • 12-bit analog-to-digital converters
  • Up to 1 billion samples (1 Gpt) on all 4 channels
  • Up to 2 GHz RF DDC bandwidth on all channels
  • 2U rack ready digitizer
  • Best in class low noise and ENOB
Bandwidth

DC to 8 GHz
Sample Rate

25 GS/S
Vertical Resolution

DC to 8 GHz
Rack Height

2U Rack Mount Ready
datasheet

Model Bandwidth Sample Rate Vertical Resolution Rack Height
LPD64 DC to 8 GHz 25 GS/s 12-bits ADC 2U rack mount ready
See more High Speed Digitizers
